SPEAKERS

CT8 SW

SUBWOOFER

PRICE 6 199CHF / pcs incl.tax (7,7%) and shipment

Picture gallery

Integral to the system’s no-compromise approach to bass management is the subwoofer, illustrated here with a pair deployed at extreme left and right for low frequencies that will push your sound envelope to the limit. The CT8 SW features a 15" driver. Like all the bass drivers in the range it features a rigid composite sandwich cone.

As you might imagine, one of the secrets of developing a high performance bass driver is finding a cone material with high enough strength to keep its shape under the heaviest of strain, yet not too heavy that it loses its responsiveness. Our choice is a modern carbon fibre and rigid foam sandwich construction used in car and aircraft bodies. Its outstanding mechanical properties and relatively low mass make it tailor-made for the job of turning low frequency effects into real-life sound.

- Technical features: Composite sandwich, cone bass, Matrix cabinet, Active bass crossover
- Description: Closed-box subwoofer
- Frequency range: -6 dB at 13 Hz and 750 Hz, -3 dB at 18 Hz and 500 Hz
- Sensitivity (2.83 V, 1 m): 93 dB spl
- Nominal impedance: 8 Ω (minimum 4 Ω)
- Recommended amplifier power: 50 W - 1000 W into 8 Ω on unclipped programme
- Max. recommended cable impedance: 0.1 Ω

Avaliability

CT8 SW

On Request

Size & Weight

NET WEIGHT

35.00 kg

PRODUCT SIZE (WxHxD)

475 x 475 x 475 mm
